Macroscopisch examination
In cases of suspected actinomycetoma, aspirated material should be examined grossly for the presence of granules by spreading the sample in a petri dish.

Granules found should be washed and crushed.

Smears should be prepared from the crushed material, and media should be inoculated.

Granules are most often seen in infections caused by N. brasiliensis, but also can be produced by other Nocardia species.

Gram stain

Gram staining is the most sensitive method by which to visualize and recognize Nocardia in clinical samples.

Clinical specimens
Beaded Gram positive rods,

0.5-1.0, thin,

filamentous and typically right angle branching.

Usually in a background of purulence with many polymorph nuclear leukocytes.

Modified Kinyoun acid fast stain

Use of the modified acid-fast stain with direct clinical samples is unreliable and should be used only to confirm the acid fastness of organisms detected by the Gram stain.

The Nocardia are often seen as partially acid-fast filamentous bacilli (showing both acid-fast and non-acid-fast Nocardia).

This acid fastness may be variable when staining colonies of Nocardia from cultured material.

Colonial acid-fast smear may be related to the type of medium used and the age of the culture, and filaments may fragment into bacilli or coccoid forms.

Obligate aerobic

BA: colonies are chalky, matte or velvety, powdery (usually), irregular, wrinkled, heaped, or smooth on surface; may be brown, tan, pink, orange, red, purple, gray, yellow, peach, or white on reverse; smooth or granular; soluble brown or yellow pigments may be present.

Cultures for Nocardia require a minimum of 48 to 72 h before colonies are evident

Colonial morphology should also be observed macroscopically and microscopically for the presence of aerial hyphae. The use of a stereoscope will allow early recognition of the aerial hyphae of Nocardia isolates, which will impart a “cotton candy” appearance to the colony surface.

Colonies should be examined for the appearance of the substrate and aerial hyphae.

Although they may be subtle, or may be absent in rare cases, the presence of aerial hyphae will differentiate the genus Nocardia from related genera, including Rhodococcus, Gordonia, Tsukamurella, Corynebacterium and Mycobacterium.

Streptomyces species and other members of the aerobic Actinomycetes may also show aerial hyphae, but these genera will not give a positive result with the modified acid-fast smear.

On slide culture Nocardia will show complex substrate hyphae branching at right angles and usually with secondary branching.

Colonial morphology of the Nocardia is variable, from the smooth, almost bacterium-like appearance of N. farcinica, which turns orange with age, to a more chalky white appearance of most other species, depending on the presence of aerial hyphae.

Isolates of N. brasiliensis typically have a yellowish coloration, and isolates of N. asteroides type VI frequently produce a brown diffusible pigment that is rarely seen with other Nocardia species.

The appearance may also differ depending upon the medium or incubation temperature. Nocardia grow readily on most nonselective laboratory media, but colonies may take from 2 to 14 days to appear.

Therefore, plates should be held for at least 2 weeks prior to being discarded and should be incubated in a humidified environment or sealed to prevent dehydration. Heavy growth of other bacterial species may therefore obscure the presence of the Nocardia on routine culture plates that may be discarded before the Nocardia colonies are detected.

Selective media may be necessary to enhance recovery of Nocardia species and minimize the growth of contaminating organisms, such as BCYE./ Buffered Charcoal Yeast agar

BBAØ: no growth

Smell moldy basement

James Versalovic et al.(2011) Manual of Clinical Microbiology 10th Edition
